Product Description
- 3.2 megapixel high resolution
- HD real-time video
- Day / night auto switch
- IP66 ingress protection
- IR LEDs :Approx 65 to 100 ft(About 20 to 30m)
- Vandal-proof housing
- 3D DNR & DWDR & BLC
Camera | |
Image Sensor | 1/3” sensor |
Min. Illumination | 0.14 [email protected], AGC on 0 lux with IR |
Shutter Speed | 1/25s ~ 1/100,000s |
Lens | [email protected] 2048 × 1536: angle of view: 86° 1920 × 1080: angle of view: 98.5° |
Lens Mount | M12 |
Angle adjustment | Pan: 0° ~ 355°, tilt: 0° ~ 65° |
Day & Night | ICR |
Digital Noise Reduction | 3D DNR |
Wide Dynamic Range | Digital WDR |
Compression Standard | |
Video Compression | H.264 / MJPEG |
H.264 codec profile | Main profile |
Bit Rate | 32 Kbps ~ 16 Mbps |
Dual stream | Yes |
Image | |
Max. Resolution | 2048 × 1536 |
Frame Rate | 60 Hz: 20fps (2048 x 1536), 30fps (1920 × 1080), 30fps (1280 x 720) 50 Hz: 20fps (2048 x 1536), 25fps (1920 × 1080), 25fps (1280 x 720) |
Image Settings | Saturation, brightness, contrast adjustable through client software or web browser |
BLC | Yes,zone configurable |
Network | |
Network Storage | NAS ( iSCSI optional) |
Alarm Trigger | Motion detection,tampering alarm,network disconnect,IP address conflict,storage exception |
Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP, IPv6 optional) |
System Compatibility | ONVIF, PSIA, CGI |
General functionalities | Flickerless, heartbeat, mirror, user authentication, video mask, watermark |
Interface | |
Communication Interface | 1 RJ45 10M / 100M ethernet port |
General | |
Working Temperature /Humidity |
-13°F ~ 140°F(-25°C ~ 60°C) humidity 95% or less (non-condensing) |
Power Supply | DC12V ± 10%, PoE (802.3af) |
Power Consumption | Max. 5.5W |
Impact protection | IEC60068-275Eh, 50J; EN50102, up to IK10 |
Ingress protection level | IP66 |
IR Range | Approx 65 to 100 ft(About 20 to 30m) |
Dimension | Φ4.4”x3.2”(Φ111.0 × 82.4 mm ) |
Weight | 1.1lb(500g) |
